浏览器插件

介绍

浏览器插件学习体系大致分为两个部分：

  1. manifest.json 中字段含义
  2. 各部分之间的通信

manifest.json

相关文档：https://developer.chrome.com/docs/extensions/mv3/manifest/
主要组成部分:

  1. background(service_worker)
  2. action
  3. options_ui
  4. content_scripts
  5. 特别提到 injected_script 不在 manifest 配置中, 但是可以通过 content_scripts 给页面插入 injected_script

各部分之间的通信

相关文档: https://developer.chrome.com/docs/extensions/mv3/messaging/

  1. content 和 background 之间的通信
  2. popup 和 content 之间的通信
  3. popup 和 background 之间的通信

content 和 background 之间的通信实例代码：

  • 短连接:
     content_scripts 发送信息给 background:

    1
    const response = await chrome.runtime.sendMessage({ greeting: "hello" });

     content_scripts 接收信息:

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    chrome.runtime.onMessage.addListener(function (
      request,
      sender,
      sendResponse
    ) {
      console.log(
        sender.tab
          ? "from a content script:" + sender.tab.url
          : "from the extension"
      );
      if (request.greeting === "hello") sendResponse({ farewell: "goodbye" });
    });

     background 发送信息给 content_scripts:

    1
    const response = await chrome.tabs.sendMessage(tab.id, { greeting: "hello" });

     background 接收信息:

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    chrome.runtime.onMessage.addListener(function (
      request,
      sender,
      sendResponse
    ) {
      console.log(
        sender.tab
          ? "from a content script:" + sender.tab.url
          : "from the extension"
      );
      if (request.greeting === "hello") sendResponse({ farewell: "goodbye" });
    });

  • 长连接:
     content_scripts 发起连接，发送消息，监听消息:

    1
    2
    3
    4
    5
    6
    7
    var port = chrome.runtime.connect({ name: "content-scripts" });
    port.postMessage({ joke: "Knock knock" });
    port.onMessage.addListener(function (msg) {
      if (msg.question === "Who's there?") port.postMessage({ answer: "Madame" });
      else if (msg.question === "Madame who?")
        port.postMessage({ answer: "Madame... Bovary" });
    });

     background 监听链接，监听消息，发送消息:

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    chrome.runtime.onConnect.addListener(function (port) {
      port.onMessage.addListener(function (msg) {
        if (msg.joke === "Knock knock")
          port.postMessage({ question: "Who's there?" });
        else if (msg.answer === "Madame")
          port.postMessage({ question: "Madame who?" });
        else if (msg.answer === "Madame... Bovary")
          port.postMessage({ question: "I don't get it." });
      });
    });

popup 和 content 之间的通信实例代码

  • 短连接, 和content与background的短链接一下

  • 长连接, popup 或者 content 任意一方都可以发起。

     popup发起连接:

    1
    2
    3
    4
    5
    6
    7
    8
    const [tab] = await chrome.tabs.query({active: true, lastFocusedWindow: true});
    const port = chrome.tabs.connect(tab.id, { name: '' })
    port.postMessage({ joke: "Knock knock" });
    port.onMessage.addListener(function (msg) {
      if (msg.question === "Who's there?") port.postMessage({ answer: "Madame" });
      else if (msg.question === "Madame who?")
        port.postMessage({ answer: "Madame... Bovary" });
    });

     content发起连接:

    1
    2
    3
    4
    5
    6
    7
    var port = chrome.runtime.connect({ name: "content-scripts" });
    port.postMessage({ joke: "Knock knock" });
    port.onMessage.addListener(function (msg) {
      if (msg.question === "Who's there?") port.postMessage({ answer: "Madame" });
      else if (msg.question === "Madame who?")
        port.postMessage({ answer: "Madame... Bovary" });
    });

     popup和content监听链接:

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    chrome.runtime.onConnect.addListener(function (port) {
      port.onMessage.addListener(function (msg) {
        if (msg.joke === "Knock knock")
          port.postMessage({ question: "Who's there?" });
        else if (msg.answer === "Madame")
          port.postMessage({ question: "Madame who?" });
        else if (msg.answer === "Madame... Bovary")
          port.postMessage({ question: "I don't get it." });
      });
    });

总结

各部分的通信其实就是各部分中对调用 chrome.runtime, chrome.tabs 的方法，实现监听消息与发送消息。原理上和各部分无关，形式上是一个发布订阅模型。
